More Flexibility, More Opportunity
VersaOBJECTNEW CO Series Flatbed UV Printers
-
LIST PRICE
CO-300-F200
CO-640-F200
CO-640-F300
CO-640-F400
CO-300-B200
CO-640-B200
POA - Roland Rental
Take object customisation to new heights with the VersaOBJECT CO Series of UV flatbed printers. Digital UV printing has never been more versatile and the CO Series is the perfect solution for customising boards, objects up to 200 mm in height and even irregular 3D objects.
- Premium quality direct-to-object or substrate printing.
- Special effect printing for added-value products.
- High-volume object customisation and personalisation.
- Available in a size and configuration to suit your business.
Roland Rental, Roland DG's finance program, is aimed to make it easy for you to purchase and pay for your new business investment.
Roland Rental enables you to enjoy the use of Roland DG equipment throughout its useful life without the associated costs of ownership including up front capital investment. Roland Rental offers a simple approval criteria and documentation to secure your Roland DG equipment.
Roland Rental is a traditional finance agreement whereby you own the asset at the end of the finance term with a nominal payment at the end of the term. It also allows you to bundle in other products, including software, with your agreement.
Flatbed UV Printing Solutions
The Ultimate in Versatile Print Production
Deliver high-quality vibrant and impactful graphics onto a vast range of objects and substrates, including metal, plastic, board, wood, canvas, vinyl, paper and much more besides, accommodating material up to 200 mm height.
Everything You Need to Succeed
Choose from 6 different models and sizes to suit your business
Power your workflow with our most intelligent engine yet
Get stunning results every time with economical ECO-UV ink
Complete range of premium after-sales services
High Quality Ink
Using the latest ECO-UV EUV5 inks for exceptional and premium-value printing, we go beyond CMYK to give you even more options and flexibility. Talk to a Roland DG expert about your print requirements to discover the ink configuration that’s right for you.
CMYK
CMYK Get premium results with high-quality CMYK EUV ink
Gloss
Generate a multitude of tangible effects, simulated embossing and gloss finishes
White
Print high-opacity white details or add sub-coats for dark or transparent materials
Red and Orange
With our True Rich Color preset, extend your available gamut and reproduce brand colours perfectly
Primer
Apply primer to the print area with precision for extensive media compatibility
Certifications
GREENGUARD Gold
ECO-UV5 inks are GREENGUARD Gold certified, meaning they meet strict standards of low chemical emissions making them ideal for indoor applications.
Key benefits
|
Broad Substrate Compatibility Print onto a virtually limitless range of flexible and rigid substrates and objects. |
|
Powerful Software Included VersaWorks 6 included, letting you print directly onto a variety of objects in a simple workflow. |
 |
The Roland DG Legacy Make a safe investment with Roland DG’s world-renowned quality and reliability. |
 |
Efficient and Fluid Workflows Produce your work, your way with flexible job-management features. |
 |
Professional Colour Management Match your customers' colour with ease thanks to advanced RIP features. |
|
No Storage Costs Reduce your reliance on screen and pad storage and make your space work for you. |
 |
Printing Distance Mode Print directly onto irregular or curved objects with a high degree of accuracy. |
|
Time Saving Turnaround Switch to digital direct-to-object printing and eliminate long set-up and finishing times. |
|
Low Running Cost Long-life print heads and ink-clogging prevention ensures long life and sustained quality. |
|
Texture Libraries Add extra expression to your prints easily with a library full of exciting printable textures. |
|
Mobile Cost Tracking Track ink usage and more in real time with the Roland DG Connect mobile app. |
 |
Fast Set-up and Ease of Use Plug in and start working immediately thanks to Roland DG’s user-friendly interface. |
VersaOBJECT CO SeriesHighlighted Features
Impressive Height and Weight Capabilities
Offering extraordinary application versatility, the CO Series can print on objects up to 200 mm in height and 100 kg/m2 in weight.
Distance Mode
The CO Series flatbed UV printers feature an innovative Distance Mode. This makes it possible to print White and CMYK inks onto convex, concave or irregular surfaces whilst maintaining excellent quality and sharpness.
Print Large Quantities of Smaller Items
Improve your productivity with a fast and efficient direct-to-object printing solution. The CO Series lets you print unique details on several items in a single print run and with VersaWorks 6 features like variable data printing, you can individually personalise each item quickly and with minimal set-up.
Safety Control Features
An emergency stop perimeter around base (and on the side of the device) safeguards operators in the busiest of production environments. Plus, there is a signal beacon with variable alerts to clearly highlight the printer status.
Low-Temperature Adjustable UV-LED lamps
Intensity of the
VersaWorks 6
Multifunctional RIP Suite
Besides its high-speed RIP functionality, VersaWorks 6 RIP includes a wide selection of productivity-boosting features for the CO Series:
- Automatically generate White, Gloss and Primer layers using Special Color Plate Generation.
- Customise larger quantities of unique items using the built-in Variable Data functionality.
Roland DG Connect App
For Everything Creative
Reduce downtime and improve work efficiency with a machine monitoring assistant that helps you gain a detailed understanding of your entire print operation while keeping your device running at optimum performance.
Create Value with Direct Printing
Introducing VersaOBJECT from Roland DG - a comprehensive solution that enable anyone to easily print directly onto 3D objects made of a variety of materials.
Peace-of-Mind
Warranty and Support
We build long-lasting, high-performance devices with unmatched customer support plus the added assurance of a Three-Year Heads N' All Warranty.
Specifications
| Model | CO-300-F200 (Flatbed) | CO-640-F200 (Flatbed) | CO-640-F300 (Flatbed) | CO-640-F400 (Flatbed) | CO-300-B200 (Belt) | CO-640-B200 (Belt) | ||
| Printing Method | Piezo ink-jet method | |||||||
| Acceptable Media | Width | 762 mm | 1,625 mm | 1,625 mm | 1,625 mm | 762 mm | 1,625 mm | |
| Thickness/Height | 0.01 to 200 mm | |||||||
| Weight Bed | 100 kg / m2 | |||||||
| Bed Size | 820 (W) x 2,050 (D) mm | 1,690 (W) x 2,050 (D) mm | 1,690 (W) x 3,065 (D) mm | 1,690 (W) x 3,625 (D) mm | 775 (W) x 1,750 (D) mm | 1,648 (W) x 1,750 (D) mm | ||
| Maximum Printing Width/Length | 749 (W) x 1,500 (L) mm | 1,612 (W) x 1,500 (L) mm | 1,612 (W) x 2,500 (L) mm | 1,612 (W) x 3,050 (L) mm | 749 (W) x Unlimited (L) mm | 1,612 (W) x Unlimited (L) mm | ||
| Ink |
Types | ECO-UV（EUV5） 220 ml cartridge（White） ECO-UV（EUV5） 500 ml cartridge（Cyan, Magenta, Yellow, Black, Red, Orange, Gloss, Primer） |
||||||
| Colours |
Eight colours (Cyan, Magenta, Yellow, Black, Red, Orange, White, Gloss) Eight colours (Cyan, Magenta, Yellow, Black, Red, Orange, White） Seven colours (Cyan, Magenta, Yellow, Black, Red, Orange, White) and Primer Seven colours (Cyan, Magenta, Yellow, Black, Red, White, Gloss) and Primer Six colours (Cyan, Magenta, Yellow, Black, White, Gloss) and Primer Six colours (Cyan, Magenta, Yellow, Black, White, Gloss） Four colours (Cyan, Magenta, Yellow, Black) |
|||||||
| Vacuum System |
Fan | 1 | 1 | 2 | 2 | 1 | 1 | |
| Vacuum Zones | ||||||||
| Printing Resolution (dpi) | Max. 1,440 dpi | |||||||
| Movement Method | High resolution stepping motor | |||||||
| Output modes | Continuous, unload, return to origin, layered | |||||||
| Media Height Setting | Manual, auto sensor | |||||||
| Surface Control | Manual, auto sensor | |||||||
| Control Interface (tower) | 7" Colour LCD touch screen | |||||||
| Interface | Ethernet Base 10/100 | |||||||
| Power-saving Function | Automatic sleep feature | |||||||
| Power Requirements | 230V 16A 2P+E | |||||||
| Power Consumption | Print with 100% Vacuum | 1.45 kw | 1.45 kw | 2.65 kw | 2.65 kw | 1.45 kw | 2.65 kw | |
| Sleep | 0.08 kw | |||||||
| Acoustic Noise Level | Print with Vacuum | < 70 dB | ||||||
| During Standby | < 40 dB | |||||||
| Dimensions | Printer Unit*1 | 1,928 (W) x 2,109 (D) x 1,490 (H) mm | 2,815 (W) x 2,109 (D) x 1,490 (H) mm | 2,815 (W) x 3,126 (D) x 1,490 (H) mm | 2,815 (W) x 3,635 (D) x 1,490 (H) mm | 1,928 (W) x 1,983 (D) x 1,490 (H) mm | 2,815 (W) x 1,983 (D) x 1,490 (H) mm | |
| Control Tower | 530 (W) x 530 (D) x 1,080 (H) mm | |||||||
| Weight (kg) | 450 + 50 kg (Control tower) | 600 + 50 kg (Control tower) | 800 + 50 kg (Control tower) | 950 + 50 kg (Control tower) | 590 + 50 kg (Control tower) | 815 + 50 kg (Control tower) | ||
| Weight Distribution | 6 points - 6 feet (80 mm diameter) | 6 points - 6 feet (80 mm diameter) | 8 points - 8 feet (80 mm diameter) | 10 points - 10 feet (80 mm diameter) | 6 points - 6 feet (80 mm diameter) | 6 points - 6 feet (80 mm diameter) | ||
| Environment | Power On | Temperature: 20 to 32ºC (68 to 90ºF) (22ºC [72ºF] or more recommended), Relative humidity: 35 to 80% (no condensation) | ||||||
| Power Off | Temperature: 5 to 40ºC (41 to 104ºF), Relative humidity: 20 to 80% (no condensation) | |||||||
| Included accessories | RIP Software, User Manual, Power Cable, Cleaning Kit, Installation Toolbox | |||||||
1Due to vertical capacity of printer, device height will vary based on media being printed. Please ensure you have sufficient vertical space above printer.
| VersaWorks 6 System Requirements | |||||
| Operating System | Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit), Windows® 7 Ultimate/Professional (32/64 bit) | ||||
| Hard-disk file system | NTFS Format | ||||
| CPU | Intel Core™ 2 Duo, 2.0 GHz or faster recommended | ||||
| RAM | 2GB or more recommended | ||||
| Video card and monitor | A resolution of 1280 x 1024 or more recommended | ||||
| Free hard disk space | 40 GB or more recommended | ||||
| Optical drive | DVD-ROM | ||||
| Ethernet Connection | 100 mbps | ||||
| Other | Internet connection recommended | ||||
