NEW Texart RT-640M Dye Sublimation Multi-Function Printer
RRP inc. GST
For 60 months inc. GSTRoland Rental
If you’re looking to start an “all-in-one” custom sign, graphics, décor and apparel business, the multi-function Texart RT-640M is the dye-sublimation printer for you. Intelligent, affordable and versatile, it offers outstanding graphic results and gives you the freedom to print onto transfer paper as well as printing direct-to-fabric.
Multi-Function for Simpler Sublimation
and Expanded Applications
The Texart RT-640M simplifies dye-sublimation production for soft-signage and textiles with a direct-to-fabric print option. It also maintains the media versatility of printing to transfer paper for rigid sign, merchandise, and hard surface customisation. The following items showcase some of the hundreds of application opportunities that the RT-640M offers.
Dye Sublimation Innovation
Includes Ergosoft Roland DG Edition 3 – Powerfully Easy RIP Software
With print modes for most common applications, ErgoSoft Roland DG Edition 3 is one of the premium RIP softwares for textile and dye-sublimation. It features standard RIP tools as well as advanced production tools to effortlessly manage your print output.
- Aurelon PDF engine with 64-bit native support to maximise performance
- RIP up to 8-jobs simultaneously, unlimited hot folders and job cost estimation
- Work in print environments and print modes for the most common dye sublimation fabrics and media
- Step & repeat and tiling features for advanced media saving and efficiency
- Job cost calculation and other advanced production features
- Superior colour management with colour replacement and extensive Colorbooks swatches
Tension Weight Take-Up
Roland DG Bulk Ink-Switching System
Super Sharp Images with Long-Lasting Colour
Multi-Function SBL3 Ink
Optimised Print Heads
Fine Media Options
Fluorescent Inks Available
Reliability, Warranty and Support
Built to provide years of reliable service – even in the most demanding print environments – Roland DG’s wide format printers come with a 1, 3 or 5 Year Warranty.
Roland DG has earned a reputation for long-lasting, high-performance devices, backed by first-rate customer service. This support includes expert technical assistance, videos and free Roland DG software updates for the lifetime of the machine.
Roland DG's international ISO certifications are your assurance of quality products and service.
|Printing Technology||Piezoelectric inkjet|
|Width||259 to 1625 mm (10.2 to 64 in.)|
|Thickness||Max. 1 mm (39 mil)
|Roll outer diameter||Max. 210 mm (8.3 in.)|
|Roll weight||Max. 40 kg (88 lb)|
|Core diameter*1||76.2 mm (3 in.) or 50.8 mm (2 in.)|
|Printing width*2||Max. 1615 mm (63.6 in.)|
|Ink||Type||Texart ink, 1000 cc pouch|
|Colors||4 colours (Cyan, Magenta, Yellow, Black)
8 colours (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Orange, Violet)
8 colours Fluorescent (Cyan, Magenta, Yellow, Black, Orange, Violet, Fluorescent Yellow, Fluorescent Pink)
|Print resolution (dots per inch)||Max. 1440 dpi|
|Distance accuracy*3||Error of less than ±0.3% of distance travelled, or ±0.3 mm, whichever is greater|
|Connectivity||Ethernet (10BASE-T/100BASE-TX, automatic switching)|
|Power-saving function||Automatic sleep feature|
|Power requirements||AC 100 to 240 V ±10%, 1.5 A, 50/60 Hz|
|Power consumption||During operation||Approx. 140 W|
|Sleep mode||Approx. 31 W|
|Acoustic noise level||During operation||62 dB (A) or less|
|During standby||49 dB (A) or less|
|Dimensions (with stand)||2650 (W) x 795 (D) x 1600 (H) mm (104.4 x 31.3 x 63 in.)|
|Weight (with stand)||160 kg (353 lb)|
|Environment||Power on||Temperature: 18 to 25°C (64.4 to 77°F), humidity: 35 to 65% RH (no condensation)|
|Power off||Temperature: 15 to 30°C (59 to 86°F), humidity: 20 to 80% RH (no condensation)|
|Included items||RIP software, take-up system, exclusive stands, power cable, media clamps, media holder, User's Manual, etc.|
|Software||ErgoSoft Roland DG Edition 3|
*1 The media holder for this machine is exclusively designed for media rolls with a paper tube measuring 76.2 mm (3 in.) in diameter. To use 50.8 mm (2in.) media rolls, the optional media flanges are required.
*2 The length of the production run is subject to the limitations of the program.
*3 Media type: Media specified by Roland DG Corporation. Temperature: 25°C (77°F), humidity: 50%. Roll media must be loaded correctly. Excluding expansion / contraction of the media. All corrections or adjustment functions of this machine have been made properly. Print travel: 1 m.
Specifications, designs and dimensions listed may be subject to change without notice.
|ErgoSoft Roland DG Edition 3 System Requirements|
|Operating system||Windows® 10 (32/64-bit)
Windows® 8/8.1 (32/64-bit)
Windows® 7 Professional (32/64-bit)
Windows® 7 Home (32/64-bit)
|CPU||Intel® Core™ i3; 3 GHz or faster recommended|
|RAM||8GB or more recommended|
|Video card and monitor||Screen resolution of 1600 x 900 or higher recommended|
|Free disk space (HDD/SSD)||100 GB or more recommended|
