monoFab ARM-10 Desktop 3D Printer

ARM-10 Rapid Prototyping 3D Printer Specifications

Build technology DLP layer projection system
Build size 130 (W) x 70 (D) x 70 (H) mm
(5.1 (W) x 2.7 (D) x 2.7 (H) inches)
(Job volume of resin is up to 300 g (0.7 lbs))
Build speed 10 mm/h (Layer pitch = 0.15 mm) (.393 inch (Layer pitch = 0.0059 inch))
Light source UV-LED (ultraviolet light emitting diode)
XY resolution 0.2 mm (.0079 inch)
Z axis resolution 0.01 mm (.0004 inch)
Power Machine:DC 24 V, 0.6 A
Dedicated AC adapter: AC 100 V to 240 V±10%, 50/60 Hz
Power consumption 15 W
Acoustic noise level During operation: 55 dB (A) or less
During standby: 49 dB (A) or less
Dimensions / Weight 430 (W) x 365 (D) x 450 (H) mm / 17 kg
17.0 (W) x 14.4 (D) x 17.8 (H) inches / 37.5 lbs
Interface USB
During operation Temperature of 20 to 30°C, 68 to 86°F, 35 to 80% relative humidity (no condensation)
Not operating Temperature of 5 to 40°C, 41 to 95°F, 20 to 80% relative humidity (no condensation)
Accessories AC adapter, Power code, USB cable, Liquid material tray, Printing and washing tools (Metalic spatula, Plastic spatula, Tweezers, Washing container x 2, Hexagonal wrench, Spanner, Rubber gloves, Work tray, etc.), Start-up page information card, Read this first.
Optionally Available Items
Item Part Number Description
Resin PRH35ST2 350g bottle
Liquid material tray LMV-10 For replacement
System Requirements (ARM-10)
Operating system (OS) Windows 7/8/8.1 (32-bit/64-bit edition)*
CPU Intel® Core 2 Duo or more (Core i5 or more recommended)
Memory (RAM) 1GB (2GB or more recommended)
Video card and monitor A resolution of 1,280x1,024 or more recommended
Free hard-disk space required
as a working space
100 megabytes or more recommended
Other requirements Internet connection and web browser,
Internet Explorer version 10 or more recommended
